Product Information
Model: JDS-08A
Insulation resistance ≥500MΩ
Mechanical life 500 times
Shell material PBT G6 UL94V-0 Black
Contact specifications Signal contact Power contact
2#
Quantity 8
Rated current 150A
Contact resistance ≤12.0mΩ ≤0.7mΩ
Working voltage / withstand voltage 380V (1000V) / 1500V (3000V)
Surface treatment Surface gold plating, bottom nickel plating Surface silver plating, bottom nickel plating
Tail termination type Socket end has crimping type (Y) and board type (B) optional, plug end is right angle through board welding
Material Pin, socket jacket Brass or copper alloy
Crown spring Beryllium bronze
The product supports hot plug and is suitable for charging pile 30-60kw power module output
JDS series module power connectors adopt advanced crown spring socket and silver plating to ensure product contact reliability Reliable connection, soft insertion and removal, low insertion force, low contact resistance, high load current, and excellent performance This series of products are mainly used in: charging piles, UPS power supply, railway signal power supply, communication power supply, power supply, power quality, photovoltaic, etc.
